Morris Products
Copper Long Barrel 2 Hole Compression Lugs #4 Awg 3/8 Stud 1" Spacing
SKU: #279260
Part: #94327
UPC: 601986943277
Morris Products
Copper Long Barrel 2 Hole Compression Lugs #4 Awg 3/8 Stud 1" Spacing
SKU: #279260
Part: #94327
UPC: 601986943277
Description
Copper Long Barrel 2 Hole Compression Lugs #4 Awg 3/8 Stud 1" Spacing - Electrical Connector
This copper long barrel 2 hole compression lug is designed for fast, reliable electrical cable terminations. Manufactured with high conductivity seamless copper tubing and electro-tin plating, it ensures efficient electrical performance and durability. Suitable for use by electrical distributors, lighting solutions providers, wire and cable specialists, and switchgear suppliers requiring secure cable connections.
Specifications
- Material: High Conductivity Seamless Copper Tubing
- Stud Configuration: 2 Hole
- Wire Size Range: #8 Stranded through 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Flammability Rating: N/A
- Material Treatment: Electro-Tin Plated
- Color: Gray
- Product Weight: 0.54 lbs
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Peep hole for inspection of proper wire insertion
- Stud size and spacing: 3/8" stud with 1" spacing
