Morris Products
Copper Long Barrel 2 Hole Compression Lugs 350 MCM 3/8 Stud 1" Spacing
SKU: #279399
Part: #94381
UPC: 601986943819
Morris Products
Copper Long Barrel 2 Hole Compression Lugs 350 MCM 3/8 Stud 1" Spacing
SKU: #279399
Part: #94381
UPC: 601986943819
Next day delivery
Description
Copper Long Barrel 2 Hole Compression Lugs 350 MCM 3/8 Stud 1" Spacing – Electrical Distributor Connector
The Copper Long Barrel 2 Hole Compression Lugs are designed for fast, reliable electrical cable terminations, commonly used by electrical distributors and switchgear suppliers in lighting solutions and wire and cable installations. Manufactured from high conductivity seamless copper tubing, these lugs ensure optimal electrical performance and durability for heavy-duty conductor connections.
- Material: High Conductivity Seamless Copper Tubing
- Stud Configuration: 2 Hole
- Stud Size: 3/8"
- Stud Spacing: 1"
- Wire Size Range: #8 Stranded through 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Material Treatment: Electro-Tin Plated
- Color Coding: Red
- Product Weight: 1.14 lbs
- Certifications: UL UL486A, cUL, RoHS Compliant
Specifications
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plating for corrosion resistance and improved conductivity
- Color coded and marked with die size and crimp marks for easy identification and installation
- Peep hole design for visual inspection of proper cable insertion
- Two-hole stud configuration for secure and reliable electrical connections
