Morris Products
Copper Long Barrel 2 Hole Compression Lugs 3/0 Awg 3/8 Stud 1" Spacing
SKU: #279358
Part: #94360
UPC: 601986943604
Morris Products
Copper Long Barrel 2 Hole Compression Lugs 3/0 Awg 3/8 Stud 1" Spacing
SKU: #279358
Part: #94360
UPC: 601986943604
Description
Copper Long Barrel 2 Hole Compression Lugs 3/0 Awg 3/8 Stud 1" Spacing – Electrical Wire and Cable Connector
This copper long barrel 2 hole compression lug is designed for fast, reliable electrical cable terminations, suitable for wire sizes ranging from #8 stranded through 750 MCM. Manufactured by Morris Products, it is ideal for electrical distributors and switchgear suppliers requiring high-quality connectors for lighting solutions and wire and cable applications.
Specifications
- Material: High Conductivity Seamless Copper Tubing
- Material Treatment: Electro-Tin Plating
- Stud Configuration: 2 Hole
- Stud Size: 3/8"
- Stud Spacing: 1"
- Wire Size Range: #8 Stranded through 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Flammability Rating: N/A
- Amp Rating: To Conductor
- Color Coding: Orange
- Product Weight: 0.1990 lbs
- Manufacturer Part #: 94360
- UPC: 601986943604
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Includes peep hole for inspection
