Morris Products
Copper Long Barrel 2 Hole Compression Lugs #2 Awg 1/2 Stud 1-3/4" Spacing
SKU: #279286
Part: #94334
UPC: 601986943345
Morris Products
Copper Long Barrel 2 Hole Compression Lugs #2 Awg 1/2 Stud 1-3/4" Spacing
SKU: #279286
Part: #94334
UPC: 601986943345
Description
Copper Long Barrel 2 Hole Compression Lugs #2 AWG 1/2" Stud 1-3/4" Spacing - Compression Lugs for Electrical Connections
This copper long barrel 2 hole compression lug is designed for fast, reliable electrical cable terminations. Manufactured from high conductivity seamless copper tubing with electro-tin plating, it ensures efficient electrical conductivity and corrosion resistance. Ideal for electrical distributors and switchgear suppliers requiring durable wire and cable connectors in lighting solutions and power distribution applications.
Specifications
- Material: High Conductivity Copper
- Stud Configuration: 2 Hole
- Stud Size: 1/2"
- Stud Spacing: 1-3/4"
- Wire Size Range: #8 Stranded through 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Color Coding: Brown
- Product Weight: 0.1130 lbs
- Certifications: UL UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for enhanced corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Includes peep hole for inspection
