Morris Products
Copper Long Barrel 2 Hole Compression Lugs 2/0 Awg 1/4 Stud 5/8" Spacing
SKU: #279332
Part: #94352
UPC: 601986943529
Morris Products
Copper Long Barrel 2 Hole Compression Lugs 2/0 Awg 1/4 Stud 5/8" Spacing
SKU: #279332
Part: #94352
UPC: 601986943529
Description
Copper Long Barrel 2 Hole Compression Lugs 2/0 Awg 1/4 Stud 5/8" Spacing - Electrical Wire Termination
This copper long barrel 2 hole compression lug is designed for fast, reliable electrical cable terminations. Manufactured by Morris Products, it is suitable for use in electrical distribution and lighting solutions where secure wire and cable connections are essential. The lug supports wire sizes from #8 stranded through 750 MCM and features a 2-hole stud configuration with 5/8" spacing, making it compatible with various switchgear and electrical equipment.
Specifications
- Material: High Conductivity Copper
- Stud Configuration: 2 Hole
- Stud Size: 1/4"
- Stud Spacing: 5/8"
- Wire Size Range: #8 Stranded thru 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Material Treatment: Electro-Tin Plated
- Product Weight: 0.75 lbs
- Color Coding: Black
- Certifications: UL UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plating for corrosion resistance
- Color coded and marked with die size and crimp marks for precise installation
- Includes peep hole for inspection of proper cable insertion
