Morris Products
Copper Long Barrel 2 Hole Compression Lugs 2/0 Awg 1/4 Stud 3/4" Spacing
SKU: #279335
Part: #94353
UPC: 601986943536
Morris Products
Copper Long Barrel 2 Hole Compression Lugs 2/0 Awg 1/4 Stud 3/4" Spacing
SKU: #279335
Part: #94353
UPC: 601986943536
Description
Copper Long Barrel 2 Hole Compression Lugs 2/0 Awg 1/4 Stud 3/4" Spacing - Electrical Wire and Cable Connector
This copper long barrel 2 hole compression lug is designed for reliable electrical cable terminations in wire and cable applications. Manufactured by Morris Products, it serves as a durable connector for electrical distributors and switchgear suppliers requiring high conductivity and secure connections.
Specifications
- Material: High Conductivity Seamless Copper Tubing
- Stud Configuration: 2 Hole
- Stud Size: 1/4"
- Stud Spacing: 3/4"
- Wire Size Range: #8 Str through 750 MCM
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Material Treatment: Electro-Tin Plated
- Color Coding: Black
- UL Certification: UL486A
- cUL: Yes
- RoHS Compliant: Yes
- Product Weight: 0.7950 lbs
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Peep hole for inspection of cable insertion
