Morris Products
Copper Long Barrel 1 Hole Compression Lugs 8 Awg - #10 Stud
SKU: #279015
Part: #94210
UPC: 601986942102
Morris Products
Copper Long Barrel 1 Hole Compression Lugs 8 Awg - #10 Stud
SKU: #279015
Part: #94210
UPC: 601986942102
Description
Copper Long Barrel 1 Hole Compression Lugs 8 Awg - #10 Stud | Copper Compression Lugs
This Copper Long Barrel 1 Hole Compression Lug is designed for reliable electrical cable terminations in industrial and commercial wiring applications. Manufactured from high conductivity seamless copper tubing with electro-tin plating, it ensures efficient electrical conductivity and corrosion resistance. Suitable for use by electrical distributors and switchgear suppliers, it supports wire sizes from #8 stranded through 750 MCM and is compatible with #10 stud configurations. Ideal for lighting solutions and wire and cable installations requiring secure compression connections.
Specifications
- Material: High Conductivity Copper
- Wire Size: #8 Stranded through 750 MCM
- Stud Configuration: 1 Hole
- Stud Size: #10
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Material Treatment: Electro-Tin Plating
- Inside Diameter: 0.173 inches
- Outside Diameter: 0.271 inches
- Product Weight: 0.3750 lbs
- Color Coding: Red
- Certifications: UL 486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for enhanced corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Includes peep hole for inspection of cable insertion
