Morris Products
Copper Long Barrel 1 Hole Compression Lugs 600 MCM - 3/4 Stud
SKU: #280415
Part: #94904
UPC: 601986949040
Morris Products
Copper Long Barrel 1 Hole Compression Lugs 600 MCM - 3/4 Stud
SKU: #280415
Part: #94904
UPC: 601986949040
Description
Copper Long Barrel 1 Hole Compression Lugs 600 MCM - 3/4 Stud
This copper long barrel compression lug is designed for fast, reliable electrical cable terminations. Manufactured from high conductivity seamless copper tubing, it is suitable for electrical distributors and switchgear suppliers requiring durable wire and cable connectors. The lug supports wire sizes from #8 stranded through 750 MCM and features a 1-hole stud configuration for secure connections in lighting solutions and other electrical applications.
Specifications
- Material: High Conductivity Copper
- Color: Green
- Inside Diameter: 0.925 inches
- Outside Diameter: 1.19 inches
- Product Weight: 0.6790 lbs
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Stud Size: 3/4 inch
- Stud Configuration: 1 Hole
- Material Treatment: Electro-Tin Plating
- Wire Size Compatibility: #8 Stranded through 750 MCM
- Certifications: UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded green for easy identification
- Marked with die size and crimp marks for precise installation
- Includes peep hole for inspection of cable insertion
