Morris Products
Copper Long Barrel 1 Hole Compression Lugs 4 Awg - 3/8 Stud
SKU: #279058
Part: #94220
UPC: 601986942201
Morris Products
Copper Long Barrel 1 Hole Compression Lugs 4 Awg - 3/8 Stud
SKU: #279058
Part: #94220
UPC: 601986942201
Description
Copper Long Barrel 1 Hole Compression Lugs 4 Awg - 3/8 Stud | Copper Compression Lugs
This Copper Long Barrel 1 Hole Compression Lug is designed for fast and reliable electrical cable terminations. Manufactured from high conductivity seamless copper tubing with electro-tin plating, it ensures excellent electrical performance and durability. Ideal for electrical distributors and lighting solutions requiring secure wire and cable connections, this lug features a 3/8 inch stud size suitable for #4 AWG wire.
Specifications
- Material: High Conductivity Copper
- Color: Gray
- Inside Diameter: .251 inches
- Outside Diameter: .344 inches
- Stud Configuration: 1 Hole
- Stud Size: 3/8 inch
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Material Treatment: Electro-Tin Plating
- Product Weight: 0.9 lbs
- Certifications: UL486A, cUL, RoHS Compliant
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Peep hole for inspection of proper cable insertion
