Morris Products
Copper Long Barrel 1 Hole Compression Lugs 350 MCM - 5/8 Stud
SKU: #279160
Part: #94267
UPC: 601986942676
Morris Products
Copper Long Barrel 1 Hole Compression Lugs 350 MCM - 5/8 Stud
SKU: #279160
Part: #94267
UPC: 601986942676
Description
Copper Long Barrel 1 Hole Compression Lugs 350 MCM - 5/8 Stud
This copper long barrel 1 hole compression lug is designed for fast and reliable electrical cable terminations. Manufactured by Morris Products, it is suitable for use by electrical distributors and switchgear suppliers requiring durable wire and cable connectors with high conductivity and precise fitting. The lug is ideal for applications in lighting solutions and electrical installations where secure and efficient connections are essential.
Specifications
- Material: High Conductivity Copper
- Color Coding: Red
- Inside Diameter: 0.700 inches
- Outside Diameter: 0.874 inches
- Product Weight: 2.0250 lbs
- Stud Size: 5/8 inch
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- UL Certification: UL486A
- cUL: Yes
- RoHS Compliant: Yes
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for easy identification
- Includes peep hole for inspection of cable insertion
