Copper Long Barrel 1 Hole Compression Lugs 3/0 - 1/4 Stud - Electrical Cable Termination Solutions

This Copper Long Barrel 1 Hole Compression Lug is designed for fast, reliable electrical cable terminations. Manufactured from high conductivity seamless copper tubing with electro-tin plating, it ensures excellent electrical performance and corrosion resistance. Suitable for use by electrical distributors and switchgear suppliers, it supports wire sizes from #8 stranded through 750 MCM and features a 1-hole stud configuration for secure connections in lighting solutions and wire and cable applications.

Specifications

• Material: High Conductivity Copper
• Color Coding: Orange
• Inside Diameter: .492 inches
• Outside Diameter: .622 inches
• Temperature Rating: 90¬∞C
• Voltage Rating: 35 KV
• Stud Configuration: 1 Hole
• Weight: 0.1500 lbs
• Certifications: UL486A, cUL, RoHS Compliant

Features

• Manufactured from high strength, high conductivity seamless copper tubing
• Electro-tin plated for enhanced corrosion resistance
• Color coded and marked with die size and crimp marks for easy installation
• Includes peep hole for inspection of proper cable insertion

Downloads & Links

• Spec Sheet
