Morris Products
Copper Long Barrel 1 Hole Compression Lugs 2 Awg - 5/16 Stud
SKU: #279063
Part: #94222
UPC: 601986942225
Morris Products
Copper Long Barrel 1 Hole Compression Lugs 2 Awg - 5/16 Stud
SKU: #279063
Part: #94222
UPC: 601986942225
Description
Copper Long Barrel 1 Hole Compression Lugs 2 Awg - 5/16 Stud
This Copper Long Barrel 1 Hole Compression Lug is designed for fast, reliable electrical cable terminations. Manufactured from high conductivity seamless copper tubing with electro-tin plating, it ensures excellent electrical performance and corrosion resistance. Suitable for use by electrical distributors and switchgear suppliers, this lug supports wire sizes from #8 stranded through 750 MCM, making it ideal for various wire and cable applications in lighting solutions and electrical distribution systems.
Specifications
- Material: High Conductivity Copper
- Stud Configuration: 1 Hole
- Stud Size: 5/16 inch
- Inside Diameter: 0.315 inches
- Outside Diameter: 0.422 inches
- Temperature Rating: 90°C
- Voltage Rating: 35 KV
- Amp Rating: To Conductor
- Color Coding: Brown
- Product Weight: 0.0630 lb
- Manufacturer: Morris Products
- Manufacturer Part #: 94222
Features
- Manufactured from high strength, high conductivity seamless copper tubing
- Electro-tin plated for corrosion resistance
- Color coded and marked with die size and crimp marks for installation accuracy
- Includes peep hole for inspection of cable insertion
