Description
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 750 MCM - Electrical Cable Termination
This Copper Flex Cable Long Barrel 2 Hole Compression Lug is designed for reliable electrical cable terminations in wire and cable applications. Manufactured by Morris Products, it is suitable for use by electrical distributors and switchgear suppliers requiring durable, high-conductivity copper lugs with precise crimping features. The lug supports flexible cables including Class G, Class H, Class I, Class K (Battery), Class M (Welding), and DLO cable constructions, making it a versatile component in lighting solutions and electrical distribution systems.
Specifications
- Material: High Conductivity Copper
- Wire Range: 750 MCM
- Stud Size: 1/2"
- Hole Spacing: 1-3/4"
- Product Weight: 1.4250 lbs
- Manufacturer Part #: 94746
- UL Listing: UL 486A, cULus Listed
- Voltage Rating: Listed for 35KV when properly installed
Features
- Flared belled entry for easy insertion of fine strand flexible cables
- Two mounting holes for secure cable termination
- Made of high-conductivity seamless electrolytic copper for optimal conductivity
- Uniform bright electro-tin plating resists corrosion and reduces contact resistance
- Crimp marks indicate proper crimp locations for consistent installation
- Compression lugs marked with die index and color codes for easy identification
