Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 400 MCM 1/2 Stud 1-3/4" Hole Spacing
SKU: #280186
Part: #94740
UPC: 601986947404
Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 400 MCM 1/2 Stud 1-3/4" Hole Spacing
SKU: #280186
Part: #94740
UPC: 601986947404
Description
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 400 MCM - Electrical Cable Termination Solutions
This copper flex cable long barrel compression lug is designed for secure and reliable electrical cable terminations. Manufactured by Morris Products, it is suitable for use with fine strand flexible cables including Class G, H, I, K (Battery), M (Welding), and DLO cable constructions. Ideal for electrical distributors and lighting solutions providers, this lug supports wire and cable applications requiring robust, corrosion-resistant connections.
Specifications
- Material: High Conductivity Copper
- Wire Size: 400 MCM
- Stud Size: 1/2 inch
- Hole Spacing: 1-3/4 inch
- Weight: 1.3650 lbs
- UL Listed: UL 486A, cULus Listed
- Voltage Rating: Listed for 35KV when properly installed
- Manufacturer Part #: 94740
Features
- Flared belled entry for easy insertion of fine strand flexible cables
- Two mounting holes for secure attachment
- Made of high-conductivity seamless electrolytic copper for superior conductivity
- Uniform bright electro-tin plating resists corrosion and reduces contact resistance
- Crimp marks indicate proper crimp locations for installation accuracy
- Compression lugs marked with die index and color codes for easy identification
