Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs #4 Awg 3/8 Stud 1" Hole Spacing
SKU: #280081
Part: #94710
UPC: 601986947107
Description
Copper Flex Cable Long Barrel 2 Hole Compression Lugs #4 Awg 3/8 Stud 1" Hole Spacing
This copper flex cable compression lug is designed for reliable electrical cable terminations in wire and cable applications. Manufactured by Morris Products, it is made from high conductivity seamless electrolytic copper and is suitable for use by electrical distributors and switchgear suppliers requiring durable and efficient cable connections. It supports fine strand flexible cables including Class G, H, I, K (Battery), M (Welding), and DLO cable constructions.
Specifications
- Material: High Conductivity Copper
- Wire Range: #4 AWG
- Stud Size: 3/8 inch
- Hole Spacing: 1 inch
- Product Weight: 0.4800 lbs
- Manufacturer Part #: 94710
- UL Listing: UL 486A, cULus Listed
- Voltage Rating: Listed for 35KV when properly installed
Features
- Flared belled entry for easy insertion of fine strand flexible cables
- Two mounting holes for secure installation
- Uniform bright electro-tin plating resists corrosion and reduces contact resistance
- Crimp marks indicate proper crimp locations for reliable terminations
- Compression lugs are marked with die index and color codes for easy identification
