Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 350 MCM 3/8 Stud 1" Hole Spacing
SKU: #280182
Part: #94738
UPC: 601986947381
Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 350 MCM 3/8 Stud 1" Hole Spacing
SKU: #280182
Part: #94738
UPC: 601986947381
Description
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 350 MCM 3/8 Stud 1" Hole Spacing - Electrical Cable Termination Solutions
This copper flex cable long barrel compression lug is designed for fast, reliable electrical cable terminations. It is suitable for use by electrical distributors and switchgear suppliers requiring high-quality wire and cable connectors. The lug accommodates 350 MCM wire size with a 3/8" stud and 1" hole spacing, providing secure and efficient connections in various electrical and lighting solutions.
Specifications
- Material: High Conductivity Copper
- Wire Size: 350 MCM
- Stud Size: 3/8"
- Hole Spacing: 1"
- Manufacturer Part #: 94738
- Product Weight: 1.14 lbs
- UL Listing: UL 486A, cULus Listed
- Voltage Rating: Listed for 35KV when properly installed
Features
- Flared belled entry for easy insertion of fine strand flexible cables including Class G, H, I, K (Battery), M (Welding), and DLO cable constructions
- Two mounting holes for secure attachment
- Made of seamless electrolytic high-conductivity copper for optimal electrical performance
- Uniform bright electro-tin plating resists corrosion, reduces contact resistance, and maximizes conductivity
- Crimp marks indicate proper crimp locations for reliable installation
- Compression lugs are marked with die index and color codes for easy identification
