Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 250 MCM 3/8 Stud 1" Hole Spacing
SKU: #280166
Part: #94735
UPC: 601986947350
Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 250 MCM 3/8 Stud 1" Hole Spacing
SKU: #280166
Part: #94735
UPC: 601986947350
Description
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 250 MCM 3/8 Stud - Electrical Cable Terminations
This Copper Flex Cable Long Barrel 2 Hole Compression Lug is designed for fast, reliable electrical cable terminations. It is suitable for use in electrical distribution and lighting solutions involving flexible cables such as Class G, Class H, Class I, Class K (Battery), Class M (Welding), and DLO cable constructions. As a component for wire and cable management, it supports secure connections with a 3/8" stud and 1" hole spacing, making it ideal for use by electrical distributors and switchgear suppliers requiring high-performance copper lugs.
Specifications
- Material: High Conductivity Copper
- Wire Size: 250 MCM
- Stud Size: 3/8"
- Hole Spacing: 1"
- Manufacturer: Morris Products
- Manufacturer Part #: 94735
- Product Weight: 1.0650 lbs
- UL Listed: UL 486A, cULus Listed
- Voltage Rating: Listed for 35KV when properly installed
Features
- Flared belled entry for easy insertion of fine strand flexible cables
- Two mounting holes for secure attachment
- Made of high-conductivity seamless electrolytic copper for optimal performance
- Uniform bright electro-tin plating resists corrosion, reduces contact resistance, and maximizes conductivity
- Crimp marks indicate proper crimp locations for reliable installation
- Compression lugs marked with die index and color codes for easy identification
