Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs #2 Awg 1/4 Stud 5/8" Hole Spacing
SKU: #280088
Part: #94712
UPC: 601986947121
Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs #2 Awg 1/4 Stud 5/8" Hole Spacing
SKU: #280088
Part: #94712
UPC: 601986947121
Description
Copper Flex Cable Long Barrel 2 Hole Compression Lugs – Electrical Cable Termination
This Copper Flex Cable Long Barrel 2 Hole Compression Lug is designed for reliable electrical cable terminations, suitable for use by electrical distributors and switchgear suppliers. It supports fine strand flexible cables including Class G, Class H, Class I, Class K (Battery), Class M (Welding), and DLO cable constructions. The lug is made of high conductivity seamless electrolytic copper with electro-tin plating to resist corrosion and enhance conductivity, making it an effective component in wire and cable applications within lighting solutions and electrical distribution systems.
Specifications
- Material: High Conductivity Copper
- Wire Size: #2 AWG
- Stud Size: 1/4"
- Hole Spacing: 5/8"
- Mounting Holes: Two
- UL Listing: UL 486A, cULus Listed
- Voltage Rating: Listed for 35KV when properly installed
- Product Weight: 0.4950 lbs
- Manufacturer: Morris Products
- Manufacturer Part Number: 94712
Features
- Flared belled entry for easy insertion of fine strand flexible cables
- Uniform bright electro-tin plating reduces contact resistance and resists corrosion
- Crimp marks indicate proper crimp locations for secure installation
- Compression lugs are marked with die index and color codes for easy identification
- Designed for use with multiple cable classes including welding and DLO cables
