Copper Flex Cable Long Barrel 2 Hole Compression Lugs 2/0 Awg 1/4 Stud 3/4" Hole Spacing

This Copper Flex Cable Long Barrel 2 Hole Compression Lug is designed for fast, reliable electrical cable terminations. Manufactured by Morris Products, it is ideal for use by electrical distributors and switchgear suppliers requiring high-quality wire and cable accessories. The lug is suitable for fine strand flexible cables including Class G, Class H, Class I, Class K (Battery), Class M (Welding), and DLO cable constructions, providing secure and efficient electrical connections in lighting solutions and other electrical applications.

Specifications

• Material: High Conductivity Copper
• Wire Size: 2/0 AWG
• Stud Size: 1/4"
• Hole Spacing: 3/4"
• Product Weight: 0.7950 lbs
• Manufacturer Part #: 94726
• UL Listed: UL 486A, cULus Listed
• Voltage Rating: Listed for 35KV when properly installed

Features

• Flared belled entry for easy insertion of fine strand flexible cables
• Two mounting holes for secure attachment
• Made of high-conductivity seamless electrolytic copper
• Uniform bright electro-tin plating resists corrosion and reduces contact resistance
• Crimp marks indicate proper crimp locations
• Compression lugs marked with die index and color codes for easy identification

Downloads & Links

• Spec Sheet
