Copper Flex Cable Long Barrel 2 Hole Compression Lugs #1 Awg 1/4 Stud 5/8" Hole Spacing - Copper Compression Lugs

This copper flex cable compression lug is designed for fast, reliable electrical cable terminations. Manufactured by Morris Products, it is suitable for use by electrical distributors, lighting solutions providers, and switchgear suppliers requiring durable and high-conductivity wire and cable connections. The lug features a long barrel and two mounting holes, optimized for #1 AWG flexible cables with 1/4" stud size and 5/8" hole spacing.

Specifications

• Material: High Conductivity Copper
• Wire Range: #1 AWG
• Stud Size: 1/4"
• Hole Spacing: 5/8"
• Product Weight: 0.6150 lbs
• Manufacturer Part #: 94718
• UL Listing: UL 486A, cULus Listed
• Voltage Rating: Listed for 35KV when properly installed
• Color Code: Green

Features

• Flared belled entry for easy insertion of fine strand flexible cables including Class G, H, I, K (Battery), M (Welding), and DLO cable constructions
• Two mounting holes for secure attachment
• Made of high-conductivity seamless electrolytic copper for maximum conductivity
• Uniform bright electro-tin plating resists corrosion and reduces contact resistance
• Crimp marks indicate proper crimp locations for reliable installation
• Compression lugs are marked with die index and color codes for easy identification
