Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs #1 Awg 1/4 Stud 3/4" Hole Spacing
SKU: #280108
Part: #94719
UPC: 601986947190
Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs #1 Awg 1/4 Stud 3/4" Hole Spacing
SKU: #280108
Part: #94719
UPC: 601986947190
Description
Copper Flex Cable Long Barrel 2 Hole Compression Lugs #1 Awg 1/4 Stud 3/4" Hole Spacing – Copper Compression Lugs
This copper flex cable long barrel compression lug is designed for reliable electrical cable terminations in wire and cable applications. Manufactured from high conductivity copper, it is suitable for use by electrical distributors and switchgear suppliers requiring durable, corrosion-resistant lugs for fine strand flexible cables. It supports various cable constructions including Class G, H, I, K (Battery), M (Welding), and DLO cables.
Specifications
- Material: High Conductivity Copper
- Wire Size: #1 AWG
- Stud Size: 1/4 inch
- Hole Spacing: 3/4 inch
- Mounting Holes: Two
- Product Weight: 0.63 lbs
- UL Listing: UL 486A, cULus Listed
- Voltage Rating: Listed for 35KV when properly installed
- Manufacturer Part Number: 94719
Features
- Flared belled entry for easy insertion of fine strand flexible cables
- Made of seamless electrolytic copper for high conductivity
- Uniform bright electro-tin plating resists corrosion and reduces contact resistance
- Crimp marks indicate proper crimp locations
- Compression lugs are marked with die index and color codes for easy identification
