Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 1/0 Awg 1/2 Stud 1-3/4" Hole Spacing
SKU: #280118
Part: #94725
UPC: 601986947251
Morris Products
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 1/0 Awg 1/2 Stud 1-3/4" Hole Spacing
SKU: #280118
Part: #94725
UPC: 601986947251
Description
Copper Flex Cable Long Barrel 2 Hole Compression Lugs 1/0 Awg 1/2 Stud 1-3/4" Hole Spacing - Electrical Cable Termination Solutions
This Copper Flex Cable Long Barrel 2 Hole Compression Lug is designed for fast and reliable electrical cable terminations. Manufactured by Morris Products, it is made of high-conductivity seamless electrolytic copper, providing superior conductivity and corrosion resistance. This product is suitable for use by electrical distributors and switchgear suppliers requiring dependable wire and cable connectors for flexible cable applications.
Specifications
- Material: High Conductivity Copper
- Wire Range: 1/0 AWG
- Stud Size: 1/2 inch
- Hole Spacing: 1-3/4 inches
- Product Weight: 0.7650 lbs
- UL Listing: UL 486A, cULus Listed
- Voltage Rating: Listed for 35KV when properly installed
- Manufacturer Part #: 94725
Features
- Flared belled entry for easy insertion of fine strand flexible cables including Class G, H, I, K (Battery), M (Welding), and DLO cable constructions
- Two mounting holes for secure attachment
- Uniform bright electro-tin plating resists corrosion, reduces contact resistance, and maximizes conductivity
- Crimp marks indicate proper crimp locations for reliable installation
- Compression lugs are marked with die index and color codes for easy identification
