Copper C-Tap 350-4/0 Main
SKU: #303908
Part: #CTH-114
UPC: 662381098139
Copper C-Tap 350-4/0 Main
SKU: #303908
Part: #CTH-114
UPC: 662381098139
Description
Copper C-Tap 350-4/0 Main – Copper Compression Connector
The Copper C-Tap 350-4/0 Main is a heavy-duty copper compression connector designed for terminating, splicing, and tapping power connectors in electrical distribution systems. This connector is suitable for grounding electrode system connections, meeting NEC250-81 and 250-91 requirements. It is rated for 600 volts and intended for use by electrical distributors and switchgear suppliers handling wire and cable applications.
Specifications
- Material: Copper
- Finish: Copper
- Color: Black
- Conductor Size: 350 MCM
- Voltage Rating: 600 Volts
- Temperature Rating: 90 °C (194 °F)
- Dimensions: Length 43.5 millimeters, Width 26.5 millimeters, Height 1.712 inches
- Mechanical Durability: Single Use
- UL Listings: UL486A Listed Wire Connector, UL467 Listed Grounding & Bonding
- Country of Origin: Mexico
- Manufacturer Part Number: CTH-114
- Order Minimum: 1
Features
- Ensures positive, all-around compression with low resistance and high pull-out values
- Made of high conductivity copper for reliable grounding connections
- Complies with NEC250 grounding electrode system requirements
- Rated for 600V applications in electrical distribution and grounding
