Conduit-PVC Coated
SKU: #62468
Part: #COND3/4SA-G
UPC: 704508321024
Conduit-PVC Coated
SKU: #62468
Part: #COND3/4SA-G
UPC: 704508321024
Next day delivery
Description
Conduit-PVC Coated – Corrosion Protection for Electrical Systems
The Conduit-PVC Coated is a corrosion-resistant aluminum conduit designed for electrical distributors and lighting solutions requiring durable wire and cable protection. Featuring a nominal 3/4 inch pipe size with a gray PVC coating, this conduit provides robust corrosion protection for electrical systems in demanding environments. It is suitable for use in electrical raceway systems where long-term durability and protection against corrosive elements are critical.
Specifications
- Material: Aluminum
- Color: Gray
- Length: 9.94 ft (3.03 m)
- Outside Diameter with PVC: 1.13 in (28.70 mm)
- Inside Diameter: 0.84 in (21.20 mm)
- Nominal Wall Thickness with PVC: 0.139 in (3.53 mm)
- Product Weight: 360.0000 (unit not specified)
- Application: Corrosion Protection for Electrical Systems
- Manufacturer: Ocal
- Manufacturer Part #: COND3/4SA-G
- Carton Quantity: 10
- Box Quantity: 900
Features
- PVC coating provides a minimum 40 mil thickness for exterior corrosion resistance
- Blue urethane coating on the interior and threads enhances corrosion protection
- Hot-dipped galvanized threads for superior thread protection
- Color-coded thread protectors for easy identification
- Meets industry standards including UL6, NEMA RN-1, ANSI C80.1
- UL Listed including UV resistance testing
- Double-coat protection with urethane coating under PVC on fittings
- Designed to extend the life of electrical raceway systems in corrosive environments
