Conduit Elbow - Standard Radius
SKU: #63337
Part: #ELL11/4SA-G
UPC: 704508370107
Conduit Elbow - Standard Radius
SKU: #63337
Part: #ELL11/4SA-G
UPC: 704508370107
Next day delivery
Description
Conduit Elbow - Standard Radius | PVC Coated Electrical Conduit Fittings
The Conduit Elbow - Standard Radius is designed to change direction for threaded, rigid conduit or when terminating at a box or fitting. This 90-degree bend fitting is fabricated from rigid aluminum with a durable 40 mil PVC coating, providing corrosion resistance suitable for demanding electrical distribution and lighting solutions. It is ideal for use in wire and cable installations requiring reliable conduit direction changes while maintaining system integrity in corrosive environments.
Specifications
- Material: Aluminum
- Color: Gray
- Finish: PVC Coated (40 mil minimum)
- Connection Type: 90 Degree Bend
- Pipe Size: 1-1/4 Inch (35 millimeters)
- Radius: 7-1/4 Inch (184.15 millimeters)
- Offset: 9-1/2 Inch (241.30 millimeters)
- Straight End Length: 2-1/4 Inch (57.15 millimeters)
- Unbent Length: 15.89 Inch (403.56 millimeters)
- Product Weight: 1.32 lbs
- Manufacturer: Ocal
- Manufacturer Part #: ELL11/4SA-G
Features
- Hot-dip galvanized steel threads with blue urethane coating for enhanced corrosion protection
- Nominal 2 mil blue urethane coating on interior and threads
- Industry-leading 40 mil minimum exterior PVC coating bonded to conduit surface
- Color-coded thread protectors for easy size identification
- Designed and manufactured to comply with ANSI C80.1, UL6, and NEMA RN-1 standards
- Suitable for use in corrosive environments, extending the life of electrical raceway systems
- Fabricated from rigid aluminum for strength and durability with corrosion resistance
