Description
Conduit Elbow - Standard Radius | PVC Coated Galvanized Conduit Fitting
The Conduit Elbow - Standard Radius is designed to change direction for threaded, rigid conduit or when terminating at a box or fitting. This 22.5-degree bend fitting is suitable for electrical distributors and switchgear suppliers requiring durable and corrosion-resistant conduit solutions. It is constructed from hot-dip galvanized steel with a gray finish and features a 40 mil PVC exterior coating and a blue urethane interior coating, ensuring long-lasting protection in demanding environments.
Specifications
- Material: Steel
- Finish: Hot-Dipped Galvanized
- Color: Gray
- Angle: 22.5 Degree Bend
- Inside Diameter: 78 millimeters
- Pipe Size: 3 Inch / 78 Metric
- Radius: 13 Inch / 330.20 Millimeters
- Offset: 16-1/2 Inch / 419.10 Millimeters
- Straight End Length: 3-1/2 Inch / 88.90 Millimeters
- Unbent Length: 27.42 Inch / 696.48 Millimeters
- Product Weight: 18.0000 lbs
- Box Quantity: 1
- Manufacturer: Ocal
- Manufacturer Part Number: ELL3221/2-G
Features
- PVC coating of minimum 40 mil thickness applied by dipping in liquid plastisol for superior corrosion resistance
- Blue urethane coating of nominal 2 mil thickness on interior and over threads for enhanced durability
- Hot-dipped galvanized steel construction for corrosion protection inside and out
- Color-coded thread protectors on each end to prevent damage during handling and installation
- Conforms to Federal Specification WW-C-581E, ANSI C80.1, UL 6, and NEMA Standard No. RN-1
- UL verified for adhesion performance including 240 hours oven conditioning at 212°F and 600 hours salt fog chamber testing
- Bendable without damage to coatings, ensuring reliable installation
