Conduit Coupling for Electrical Distributor and Wire and Cable Applications

This conduit coupling provides corrosion-protected connections for conduit sections, suitable for use in electrical distribution and lighting solutions. Designed for 3/4 inch (21 mm) trade size conduit, it features a galvanized rigid steel construction with a PVC coating and blue urethane coating on the interior and threads for enhanced durability and corrosion resistance.

Specifications

• Trade Size: 3/4 Inch / 21 mm
• Material: Steel
• Length: 3.75 in / 95.25 mm
• Color: Light Blue
• Thread Type: Straight Threads (NPS)
• Coating: Minimum .040 inch (40 mil) PVC bonded exterior, Nominal .002 inch (2 mil) blue urethane interior and exterior
• Application: Corrosion-Protected Connections for Conduit Sections
• Box Quantity: 90

Features

• Pressure sealing sleeves protect the connection
• Molded ribs on outer coating for easy installation (up to and including 4 inch sizes)
• Blue urethane coating on interior and threads enhances corrosion resistance
• Galvanized rigid steel construction for durability

Downloads & Links

• Spec Sheet
• Technical Drawing / Spec Sheet
• Catalog US
• Support/Tools
• Technical Drawing / Spec Sheet Canada
