Features

• An Electrochemical Co Sensor
• The Unit Shall Perform Self-Diagnostic Tests and Issue a Malfunction Warning Audibly (Three Chirps) if the Unit Malfunctions
• A Visual LED Power-On Indicator to Confirm Unit is Receiving Power or to Confirm Unit has Switched to Battery Backup Mode
• A Test/Silence Button to Check all Alarm Functions and to Silence any Nuisance Alarms
• In Addition the Unit Shall have a Low Battery Silence Feature to Quiet the Low Battery Chirp for up to Eight Hours

Additional Information

• Overall Dimensions 5.4 Inch Diameter x 1.9 Inch Height
• Operating Current 0.09 Amp (Standby/Alarm)
• Color White
• Reset Type Automatic
• Temperature Rating 40 to 100 Deg F
• Relative Humidity Rating 10 to 95 Percent
• Includes 9 Volt Battery Backup

Specifications

• Type: Carbon Monoxide Alarm, Hardwired, Wire-In
• Operation Type: Electrochemical
• Voltage Rating/Source: 120 Volt AC 60 Hertz
• LED/Strobe Type: Green LED Indicating AC Power, DC Power, Red LED Indicating Local Alarm, Alarm Latch, Remote Alarm
• Horn Type: 85 Decibel at 10 Foot
• Number of Interconnections: 18
• Approval: CAN/ULC S531, ETL
