Specifications

• Height: 3.115 in | 79.121 mm
• Length: 8.372 in | 212.6488 mm
• Weight: 2.37 lbs
• Width: 3.147 in | 79.9338 mm

Additional Class Attributes

• Connection: Mechanical
• Contains DE-OX®: Yes
• Number of Conductors: 6
• Number of Poles: 1
• Number of Ports / Wireways: 6
• Number of Usable Ports: 6

Dimensions

• Drive Size Main: 3/8
• Drive Type Main: Internal Hex
• Height BX (IN): 6.5
• Height (mm): 79.121
• Length (mm): 212.6488
• Max Insulation OD (IN): 1.172
• Max Insulation OD (mm): 29.7688
• Weight BX (LB): 7.8127
• Width BX (IN): 12.75
• Width (mm): 79.9338

Material and Finish

• Conductor Material: Copper, Aluminum
• Connector Finish: Tin
• Insulation: Plastisol
• Material: Aluminum
• Wire Binding Hardware Finish: Tin
• Wire Binding Hardware Material: Aluminum

Bolt and Screw Sizes

• Number of Wire Binding Screws per Port: 1
• Wire Binding Screw Size: 13/16
• Wire Binding Torque: 375

Conductor Ranges

• Conductor Range AL Stranded (Primary, run, main, line): 600 kcmil - 4 Str
• Conductor Range CU Stranded (Primary, run, main, line): 600 kcmil - 4 Str

Color

• Color: Clear

Additional Technical Specifications

• Connector Amperage Rating CU (Derated where applicable): 475 Amps
• Conductor Type: Stranded

Voltage

• Voltage Rating: 600 V

Testing Standards

• CSA File Number: LR-29601
• CSA Standard: C22.2 No. 65-03
• Prop65 Compliance: WARNING: Cancer and Reproductive Harm - www.P65warnings.ca.gov
• UL Control Number: 453G
• UL / CULUS Specification: UL 486A/B Listed
• UL File Number: E6207

Environment and Temperature

• Environmental Conditions: Cold temperature rated to -45°C
• Flammability Rating: Insulation rated per UL 94
• Temperature Rating: 90°C

General

• Bag Quantity: 1
• Carton Quantity Description: STD PACK QTY 3
• Dual Rated: Yes
• NEMA Code: S-588-4
• UPC Code: 78366970068
