Morris Products
Chair Adapter (3 Male tabs)
SKU: #271739
Part: #10718
UPC: 601986107181
Morris Products
Chair Adapter (3 Male tabs)
SKU: #271739
Part: #10718
UPC: 601986107181
Description
Chair Adapter (3 Male tabs) Electrical Connector
The Chair Adapter (3 Male tabs) by Morris Products is a non-insulated electrical connector designed for use in wire and cable applications requiring reliable multi-way connections. It serves as a component for electrical distributors and switchgear suppliers seeking durable and precise connectors for lighting solutions and general electrical distribution.
Specifications
- Material: Brass
- Voltage Rating: 600 V
- Amp Rating: 24 Amps
- Wire Range: 22-10 AWG
- Tab Size: 0.25 inches
- Length: 0.827 inches
- Width: 0.299 inches
- Flammability Rating: UL94V-0
- Certifications: UL, cUL, RoHS
- Product Weight: 0.0060 lbs
Features
- Non-insulated design for direct electrical contact
- Manufactured from high strength brass for durability
- Three parallel .250 inch male tabs with one in-line .250 inch female tab
