CH225 Circuit Breaker by Eaton - Residential Electrical Protection

The Eaton CH225 is a 2-pole, 25-ampere plug-on circuit breaker designed for residential electrical distribution. It provides premium overload protection with a thermal-magnetic trip curve that prevents nuisance tripping on mild overloads while responding instantly to severe short circuits. Ideal for use in residential loadcenters, this breaker ensures reliable circuit protection and is suitable for 120/240 Vac applications.

Specifications

• Manufacturer: Eaton
• Manufacturer Part #: CH225
• Current Rating: 25 amperes
• Number of Poles: 2
• Mounting Type: Plug-On
• Product Weight: 0.5600 lbs

Features

• Quick-make, quick-break switch mechanism with trip-free handle design
• Thermal-magnetic trip curve for accurate overload and short-circuit protection
• Trips to OFF position to eliminate nuisance callbacks
• Handles marked with ON-OFF indication and ampere rating
• Internal common trip connection to operate both poles simultaneously

Downloads & Links

• Catalog
