CH 3/4-inch loadcenter
SKU: #161465
Part: #CH24L150D
UPC: 782113097718
CH 3/4-inch loadcenter
SKU: #161465
Part: #CH24L150D
UPC: 782113097718
Next day delivery
Description
CH 3/4-inch loadcenter – Loadcenter Electrical Panel
The Eaton CH 3/4-inch loadcenter is a single-phase electrical panel designed for use in residential and light commercial applications. It is suitable for main lug only service equipment installations with overhead or underground feed types. This loadcenter supports up to 24 circuits and provides reliable distribution of electrical power with copper bus material and a metallic enclosure.
Specifications
- Manufacturer: Eaton
- Manufacturer Part #: CH24L150D
- Amperage: 150 amperes
- Number of Circuits: 24
- Number of Wires: 3
- Number of Phases: 1
- Feed Type: Overhead/Underground
- Bus Material: Copper
- Enclosure Material: Metallic
- Enclosure Rating: NEMA 1
- Circuit Breaker Type: CH
- Product Weight: 17.9 lbs
- Dimensions: Height 3.88 in, Length 21 in, Width 14.31 in
Features
- Main lug only design suitable for service equipment with up to six service disconnecting mains
- Compatible with Eaton CH main circuit breakers and main breaker kits (Csh2100n, csh2121n)
- Supports wire sizes from #4 to 300 kcmil
- Standard configuration for residential and light commercial lighting and appliance circuits
- Durable metallic enclosure with NEMA 1 rating for indoor use
- Limited lifetime warranty
