Features

• Surface Style with Cover Insert
• 180 Degree Cover Opening to Lay Flat and Reduce Tripping Hazards
• Two Large Cable Egress Doors
• Die Cast Aluminum Cover Construction for Enhanced Durability
• Meets UL 514A Scrub Water Requirements
• ADA Compliant
• Low Profile Surface Cover with Insert Option with Two Large Cable Egress Doors

Specifications

• Country of Origin: United States
• Application - For Use On: Concrete
• Cover Shape: Rectangle
• Width: 14.800 in
• Each - Width: 14.800 in
• Industry Standard(s): cULus;UL514
• Mounting Method: Mounts to Box
• Size: 2-Gang;4-Gang
• Type of Use: Carpet/Surface
• Typical Application: Carpet/Surface
• Application: For Use with Concrete Floor Boxes
• Cable Entry: (2) Egress Doors
• Color: Aluminum Powder Coat
• Length: 11.69 in
• Mounting: (4) Screw Mount
• Special Features: Low Profile Surface Cover with Insert Option with Two Large Cable Egress Doors
• Standard: cULus;UL514
• Type: Recessed Concrete Floor Box Cover w/ Carpet Insert
• Cover Type: Rectangle
• Finish Type: Aluminum
• Mounting Type: (4) Screw Mount
• Description - Invoice: 2/4G CARPET CVR, INSERT, ALUMINUM POWDER
• Freight Class Code: 06168002
• Harmonization Code: 7616995190
• Image Actual Or Representative: A
• MSDS Flag: No
• Construction: Cast Aluminum
• Material: Cast Aluminum
• Number of Gang(s): 2-Gang
• Series: Recessed - CFB Series
• Base Unit of Measure: EA
• BOX SIZE: 3.900x15.400x14.800 (in)
• Carton - SCC-14 Next Lower Level Sub Pack: 00783585527161
• Case Weight: 3.550 lb.
• Pallet Height: 46.800 in
• Pallet Length: 48.000 in
• Pallet Weight: 340.800 lb.
• Pallet Width: 40.000 in

Certifications

• EU RoHS Indicator: Contact Manufacturer
