Cat6 (RJ45) Unshielded Keystone Jacks Lt Almond - Data Communications Connectivity

The Cat6 (RJ45) Unshielded Keystone Jack in Lt. Almond is designed for datacommunications applications, providing reliable network connectivity for electrical distributors and lighting solutions providers. It supports high-performance wire and cable installations and is suitable for use by switchgear suppliers requiring quality connectivity components.

Specifications

• Category: Cat6 (RJ45) Unshielded Keystone Jack
• Bandwidth: 250 MHz
• Data Rate: 10 Gbps
• Termination: 110 Punchdown & Krone Type
• Conductor Compatibility: 8 Conductor 22-26 AWG Solid & Stranded Wire
• Wiring Standard: 568A & 568B Color Coded
• Contact Plating: 50µ Gold Plated Contacts
• Flammability Rating: UL94V-0
• Color: Lt. Almond
• Manufacturer: Morris Products
• Manufacturer Part Number: 88428
• Product Weight: 0.0750 lbs

Features

• Improved insertion loss, return loss, and NEXT & FEXT characteristics for higher signal-to-loss ratios and reliable network performance
• Complies with TIA/EIA-568-C-2, ISO 1801 2nd Edition Class E, and NEC Article 800 standards
• Rear conductor termination for efficient cable management
• Fits all standard 19" racks, brackets, and cabinets

Downloads & Links

• Spec Sheet
