Cat 5e 110-Style Wiring Block, Wall Mount w/ legs, 100-Pair
SKU: #14411
Part: #41AW2-100
UPC: 078477190807
Cat 5e 110-Style Wiring Block, Wall Mount w/ legs, 100-Pair
SKU: #14411
Part: #41AW2-100
UPC: 078477190807
Description
Cat 5e 110-Style Wiring Block, Wall Mount w/ legs, 100-Pair – Cross Connect Wiring Solutions
The Leviton Cat 5e 110-Style Wiring Block is a wall-mount cross-connect solution designed for terminating 22-26 AWG solid copper wire in voice, security, and data applications. It meets and exceeds Category 5e transmission requirements, making it suitable for high megabit data networks. This wiring block is ideal for use by electrical distributors and switchgear suppliers in building entrance facilities, telecommunications closets, and equipment rooms. It supports 110 termination and can be mounted on walls or backboards, providing a reliable infrastructure for wire and cable management.
Specifications
- Manufacturer: Leviton
- Manufacturer Part #: 41AW2-100
- Product Weight: 0.663 lbs
- Pair Density: 100-Pair
- Mounting: Wall-mount with legs
- Wire Gauge Compatibility: 22-26 AWG solid copper wire
- Standards Compliance: UL Listed, ANSI/TIA-568-C.2 compliant
- Material: Fire-retardant plastic rated UL 94V-0
Features
- Supports voice, security, and high-speed data applications with Cat 5e rated cabling
- 110-style termination blocks provide centralized and organized cable management
- Legs included for mounting stability and cable routing underneath
- Compatible with ANSI/TIA-606-B compliant labeling for circuit identification
- Designed for easy installation on walls or backboards with appropriate hardware
- Non-conductive modular ports ensure electrical isolation per UL 1863
- Durable construction with fire-retardant plastic ensures safety and longevity
