Cable Protector Fuse 600V 500 MCM CU Cable To Blade Mount CP Series
SKU: #196164
Part: #CP500C3
UPC: 782001931643
Cable Protector Fuse 600V 500 MCM CU Cable To Blade Mount CP Series
SKU: #196164
Part: #CP500C3
UPC: 782001931643
Description
Cable Protector Fuse 600V 500 MCM CU Cable To Blade Mount CP Series – Cable Protector Fuse
Mersen's Cable Protector Fuse CP Series is designed for service entrance and distribution runs, providing reliable fault clearing and isolation. These special purpose current-limiting devices are crimped or bolted to copper cables, offering a 200,000A interrupting rating at 600VAC. They effectively carry low cable overloads managed by standard protective devices, enhancing system reliability. Suitable for electrical distributors and switchgear suppliers focusing on wire and cable protection.
Specifications
- Application: Service entrance and distribution runs
- Voltage Rating: 600VAC
- Interrupt Rating: 200 kA
- Cable Size: 500 MCM Copper
- Connection: Blade To Cable
- Mounting Type: Bolted, Crimp
- Dimensions (L x W x H): 10 in x 1.88 in x 1.88 in
- Diameter: 1.88 inches
- Max. Operating Temperature: 80 degrees Celsius
- Product Weight: 2.44 lbs
- Country of Origin: Mexico
- Manufacturer: Mersen
- Manufacturer Part Number: CP500C3
Features
- Current-limiting device with 200,000A interrupting rating
- Crimp terminals with oxide inhibitor for aluminum cables
- Fiberglass body ensures dimensional stability in harsh environments
- Catalog number permanently stamped on terminal for identification
- Optional heat shrinkable tubing available for field installation
- Permitted by National Electrical Code®
- Compatible with class J fuses for cables smaller than 4/0
