Cable Protector Fuse 600V 4/0 CU Cable To Blade Mount CP Series
SKU: #196161
Part: #CP4/0C3
UPC: 782001937416
Cable Protector Fuse 600V 4/0 CU Cable To Blade Mount CP Series
SKU: #196161
Part: #CP4/0C3
UPC: 782001937416
Description
Cable Protector Fuse 600V 4/0 CU Cable To Blade Mount CP Series – Cable Protection Fuse
The Mersen Cable Protector Fuse CP Series is designed for service entrance and distribution runs, providing reliable current-limiting protection for copper cables up to 600V. This cable protector fuse quickly clears and isolates faults to enhance electrical system reliability. It is suitable for electrical distributors and switchgear suppliers requiring robust protection solutions for wire and cable installations.
Specifications
- Application: Service entrance and distribution runs
- Voltage Rating: 600 VAC
- Interrupt Rating: 200 kA
- Cable Size: 4/0 copper (CU)
- Connection: Blade to Cable
- Mounting: Crimp and Bolted (Bolted type)
- Dimensions (L×W×H): 8.87 in × 1.44 in × 1.44 in
- Diameter: 1.44 inches
- Maximum Operating Temperature: 80 degrees Celsius
- Product Weight: 1.3 lbs
- Country of Origin: Mexico
- Manufacturer Part Number: CP4/0C3
Features
- Current limiting device with a 200,000A interrupting rating
- Fiberglass body ensures dimensional stability in harsh environments
- Catalog number permanently stamped into terminal for identification
- Crimp terminals include oxide inhibitor for aluminum cables (applicable to aluminum variants)
- Heat shrinkable tubing available for field installation insulation and protection
- Permitted by National Electrical Code®
