CA 15A USB Tamper Resist White USB Receptacle

This Lutron CA 15A USB Tamper Resistant Receptacle is designed for residential and commercial electrical installations, providing integrated USB charging ports alongside standard receptacle outlets. It is suitable for electrical distributors and lighting solutions providers seeking to offer wire and cable accessories with enhanced safety and convenience. The device features two USB Type A 2.0 ports delivering a combined 3.8 Amp output, ideal for charging multiple devices simultaneously. Its tamper-resistant shutter mechanism prevents insertion of foreign objects, meeting safety standards for switchgear suppliers.

Specifications

• Name: CA 15A USB TAMPER RESIST WHITE
• Amperage Rating: 15 A
• NEMA Rating: 5-15R
• Connection Type: Screw-Type Terminals
• Mounting Type: Wallbox
• Number of Poles: 1
• Number of Wires: 3
• Material: Plastic/Metal
• Insulation Material: Plastic
• Color: White
• Environmental Conditions: 0 to 90% humidity, non-condensing
• Product Weight: 0.4 lb
• Manufacturer Part Number: CAR-15-UBTR-WH
• USB Output: 2 USB Type A 2.0 ports, combined 3.8 Amp output

Features

• Includes permanently installed internal tamper-resistant shutter mechanism for enhanced safety
• Compatible with Lutron Claro wall plates for consistent aesthetic coordination (sold separately)
• Installation options include screw terminals or push-in connections
• USB ports rated for a minimum of 10,000 insertions and removals
• Designed for easy installation in standard electrical wallboxes (minimum 3" x 2" x 2.5")
• Meets electrical codes with durable plastic and metal construction

Downloads & Links

• Spec Sheet
• Spec Sheet
