BURNDY Insulation Piercing Connector
SKU: #331044
Part: #BIPC1/02
UPC: 781810128701
BURNDY Insulation Piercing Connector
SKU: #331044
Part: #BIPC1/02
UPC: 781810128701
Description
BURNDY Insulation Piercing Connector Electrical Connector
The BURNDY Insulation Piercing Connector is designed for splicing and tapping aluminum and copper conductors in electrical distribution systems. It supports wire sizes from 8 to 1/0 AWG for the run conductor and 8 to 2 AWG for the tap conductor, rated for 600 volts. This connector is suitable for applications requiring reliable electrical connections without stripping insulation, commonly used by electrical distributors and switchgear suppliers.
Specifications
- Application: For Splicing And Tapping Aluminum And Copper Conductors
- Voltage Rating: 600 V
- Run Conductor Size: 8-1/0 AWG
- Tap Conductor Size: 8-2 AWG
- Material: Aluminum
- Insulation: Yes
- Product Weight: 0.2400 lbs
- Direct Burial: No
- Country of Origin: United States
- Manufacturer: Burndy
- Manufacturer Part #: BIPC1/02
- Made in USA: Yes
Features
- Insulation piercing design eliminates the need to strip wire insulation
- Compatible with both aluminum and copper conductors
- Durable aluminum construction for corrosion resistance
- Suitable for use in electrical distribution and wiring systems
