BURNDY BBB14210A BUSBAR 1/4X2X10 16HOLE
SKU: #400034
Part: #BBB14210A
UPC: 781810489314
BURNDY BBB14210A BUSBAR 1/4X2X10 16HOLE
SKU: #400034
Part: #BBB14210A
UPC: 781810489314
Description
BURNDY BBB14210A Busbar Electrical Grounding Solution
The BURNDY BBB14210A is a copper busbar designed for electrical grounding applications. It is UL Listed and suitable for use as a common ground point or in power distribution setups. This busbar is ideal for electrical distributors and switchgear suppliers requiring reliable grounding and busbar solutions for wire and cable management.
Specifications
- Material: Electrical grade copper
- Dimensions: 1/4" thickness x 2" width x 10" length
- Number of Holes: 16
- Product Weight: 2.6 lbs
- Manufacturer Part #: BBB14210A
- UPC: 781810489314
- T-Bar Thickness: 1/4"
- W-Bar Width: 2 in
- L-Bar Length: 10 in
- E1 Dimension: 0.63 in
- F1 Dimension: 1.00 in
- K Dimension: 0.28 in
Features
- Bare copper construction ensures excellent conductivity and durability
- Pre-assembled with one busbar, two insulators, two mounting brackets, and four screws
- Includes brackets and insulators for secure mounting
- UL Listed for grounding applications
- Suitable for horizontal or vertical mounting configurations
- Multiple hole patterns for flexible wiring and cable connections
