BRKR HHED6 3P 600V 25A Molded Case Circuit Breaker

This Siemens molded case circuit breaker is designed for low voltage electrical distribution and protection applications. It features a thermal-magnetic trip unit with a standard 40°C operating temperature rating. The breaker is suitable for use in lighting solutions, wire and cable systems, and as part of switchgear supplied by electrical distributors. It provides reliable circuit protection with an extra high interrupting capacity and is rated for use at 600V AC with 3 poles and a 25A current rating.

Specifications

• Manufacturer: Siemens
• Manufacturer Part #: HHED63B025
• Frame Type: ED
• Number of Poles: 3
• Interrupt Rating: 18KAIC at 600V
• Frequency Rating: 50/60 Hz
• Operating Temperature: 40¬∞C
• Dimensions (W x H x D): 6.00 in x 7 in x 4.00 in
• Weight: 4.0 lbs
• Application: Standard 40¬∞C Breaker
• Country of Origin: Mexico

Features

• Thermal-magnetic trip unit with non-interchangeable design for enhanced safety and compliance
• Extra high breaking capacity suitable for demanding electrical distribution systems
• Load lugs only with wire range of 14-10 AWG copper and 12-10 AWG aluminum conductors
• Rotatable load terminals for flexible wiring installation
• Push-to-trip button for manual trip testing and operational verification
• Compliant with UL 489 and CSA C22.2 No. 5 standards
• Designed for use in individual enclosures, panelboards, and switchboards
