BRKR BQ 3P 240V 40A 10K
SKU: #308489
Part: #BQ3B040
UPC: 783643102613
BRKR BQ 3P 240V 40A 10K
SKU: #308489
Part: #BQ3B040
UPC: 783643102613
Next day delivery
Description
BRKR BQ 3P 240V 40A 10K Molded Case Circuit Breaker
Siemens BRKR BQ 3P 240V 40A 10K is a low voltage molded case circuit breaker designed for circuit protection in electrical distribution systems. This 3-pole common-trip MCCB is suitable for industrial and commercial applications requiring reliable interruption of electrical faults. It is ideal for use by electrical distributors and switchgear suppliers seeking durable and certified circuit protection solutions.
Specifications
- Manufacturer: Siemens
- Manufacturer Part #: BQ3B040
- Number of Poles: 3
- Rated Voltage: 240V AC
- Rated Current: 40 Amps
- Interrupting Rating (AIR): 10 kA
- Dimensions (W x H x L): 3.95 in x 2.95 in x 2.95 in
- Product Weight: 0.98 lbs
- Country of Origin: Mexico
- UPC: 783643102613
Features
- General purpose molded case circuit breaker for low voltage applications
- Common-trip mechanism for 3 poles
- Load side lugs included for easy installation
- Calibrated for 40°C maximum ambient temperature
- CSA Certified and UL Listed for use with 60/75°C wire
- HACR rated for HVAC applications
