BRKR 3VA41 1(2)P 40A 25KA Molded Case Circuit Breaker

The Siemens 3VA41 molded case circuit breaker is designed for low voltage electrical distribution and protection. It features a thermal-magnetic trip unit suitable for electrical distributors and switchgear suppliers requiring reliable overcurrent protection. This breaker is ideal for use in lighting solutions, wire and cable applications, and other electrical systems requiring robust circuit interruption capabilities.

Specifications

• Frame: 3VA41
• Poles: 1 (2-pole configuration)
• Current Rating: 40A
• Breaking Capacity: 14kA at 600Y/347V, 25kA at 277V
• Trip Unit: TM210 Thermal-Magnetic with fixed Ir and fixed Ii
• Dimensions (W x H x D): 5.31 in x 2.28 in x 6.61 in
• Weight: 1.11 lbs
• Manufacturer Part Number: 3VA4140-4ED54-0AA0
• Installation: Lugs installed on load side only

Features

• Thermal-magnetic trip unit for precise overcurrent protection
• Standard (Class S) breaking capacity for enhanced safety
• Compact design suitable for various electrical distribution panels
• Load side lug installation simplifies wiring and maintenance
• UL listed for compliance with safety standards
