Morris Products
Black Insulated Multi-Cable Connector - Single Entry 3 Ports 4 - 14
SKU: #280938
Part: #97513
UPC: 601986975131
Morris Products
Black Insulated Multi-Cable Connector - Single Entry 3 Ports 4 - 14
SKU: #280938
Part: #97513
UPC: 601986975131
Description
Black Insulated Multi-Cable Connector - Single Entry 3 Ports 4 - 14 Electrical Connector
The Black Insulated Multi-Cable Connector is designed for efficient cable splicing and tapping in electrical distribution systems. Manufactured from 6061-T6 aluminum with black abrasion and chemical-resistant PVC insulation, this connector supports wire ranges from #4 to #14. It is suitable for use in gutter, raceway, and enclosure power distribution applications, serving electrical distributors and lighting solutions providers requiring reliable wire and cable connectivity.
Specifications
- Material: 6061-T6 Plated Aluminum
- Color: Black
- Insulation: Black Abrasion & Chemical Resistant PVC
- Wire Range: #4 - #14
- Temperature Rating: 49°F - 194°F
- Voltage Rating: 600V
- Amp Rating: To Conductor
- UL Certification: UL 486B Dual Rated CU/AL ANSI C119.4
- cUL: Yes
- Weight: 0.1200 lb
Features
- Insulated Mechanical Connector with black PVC insulation
- Multi-tap single directional conductor entry for simplified cable splicing
- Aluminum mechanical connector, AL/CU dual rated for aluminum and copper conductors
- Prefilled oxide inhibitor for enhanced conductivity and corrosion resistance
