Black Insulated Multi-Cable Connector - Dual Entry 5 Ports 2 - 14 | Electrical Connector

This Black Insulated Multi-Cable Connector by Morris Products is designed for electrical distributors and lighting solutions providers requiring reliable wire and cable splicing and tapping. Featuring dual side entry for multi-tap applications, it facilitates simple, fast, and secure electrical power connections in gutter, raceway, and enclosure power distribution systems.

Specifications

• Material: 6061-T6 Plated Aluminum
• Insulation: Black Abrasion & Chemical Resistant PVC
• Wire Range: #14 to 2 AWG
• Temperature Rating: 40¬∞F to 194¬∞F
• Voltage Rating: 600 V
• UL Certification: UL 486B Dual Rated CU ANSI C119.4
• cUL: Yes
• Product Weight: 0.2700 lbs

Features

• Insulated mechanical connector with black PVC insulation for durability
• Multi-tap dual directional conductor entry for flexible wiring configurations
• Aluminum mechanical connector suitable for aluminum and copper conductors (AL/CU dual rated)
• Prefilled with oxide inhibitor to protect connections from corrosion
• Designed for use in power distribution applications including gutters, raceways, and enclosures
