Morris Products
Black Insulated Multi-Cable Connector - Dual Entry 4 Ports 2 - 14
SKU: #281283
Part: #97625
UPC: 601986976251
Morris Products
Black Insulated Multi-Cable Connector - Dual Entry 4 Ports 2 - 14
SKU: #281283
Part: #97625
UPC: 601986976251
Description
Black Insulated Multi-Cable Connector - Dual Entry 4 Ports 2 - 14 | Electrical Power Connector
This Black Insulated Multi-Cable Connector is designed for efficient electrical power distribution and splicing applications. Manufactured by Morris Products, it features a dual entry design with four ports supporting wire sizes from 2 to 14 AWG. Ideal for electrical distributors and lighting solutions providers, this connector facilitates fast, reliable tapping and splicing in gutter, raceway, and enclosure power distribution systems.
Specifications
- Material: 6061-T6 Plated Aluminum
- Color: Black
- Insulation: Black Abrasion & Chemical Resistant PVC
- Wire Range: #14 to 750 MCM
- Temperature Rating: 49°F to 194°F
- Voltage Rating: 600V
- Amp Rating: To Conductor
- UL Certification: UL 486B Dual Rated CU ANSI C119.4
- cUL: Yes
- Product Weight: 0.2400 lbs
Features
- Insulated mechanical connector with black PVC insulation
- Multi-tap dual directional conductor entry for simplified splicing and tapping
- Aluminum mechanical connector compatible with aluminum and copper conductors (AL/CU dual rated)
- Prefilled with oxide inhibitor to enhance conductivity and prevent corrosion
- Suitable for gutter, raceway, and enclosure power distribution applications
