Features

• Bends a wide variety of types and sizes of conduit
• Durable ratchet mechanism for easy bending
• Bypass the ratchet for fast, direct bending on smaller sizes
• Bending degree indicator and charts for fast, easy, accurate bending
• All shoe and bending tool accessories can be mounted to the frame unit and secured with a chain and lock
• Heavy-duty undercarriage with wheels
• Does not include handle

Application

• Conduit Bending

Specifications

• Country of Origin: United States
• Construction: Steel And Aluminum
• Centerline Bend Radius: 5-3/32'' (129.400 MM) - 9-3/16'' (233.400 MM) (EMT) for 3/4'' - 2.000'' Shoe Size, 2-21/32 IN (67.500 MM) - 7-3/8'' (187.300 MM) (IMC) for 1/2'' - 1-1/4'' Shoe Size, 2-21/32'' (67.500 MM) - 9.000'' (228.600 MM) (Rigid) for 1/2'' - 1-1/2'' Shoe
• Conduit Size: 3/4" – 2" EMT 1/2" – 1-1/4" IMC1/2" – 1-1/2" Galvanized Rigid Conduit2" Aluminum (only) Rigid Conduit
• Type: Mechanical Bender
• Conduit Type: EMT, IMC, Rigid And Aluminum Rigid
• Replacement Part: 1818G1 Frame And Undercarriage Unit Only, 19988G Wheel, Non-flat
