BC-MSM Conduit to Beam Clamp, Side Mount, 1/2", 3/4" EMT, 1/2", 3/4" Rigid/Pipe, 0.709"–1.181" OD, 0.5" Max Flange
SKU: #284958
Part: #BC812MSM
UPC: 782856198109
BC-MSM Conduit to Beam Clamp, Side Mount, 1/2", 3/4" EMT, 1/2", 3/4" Rigid/Pipe, 0.709"–1.181" OD, 0.5" Max Flange
SKU: #284958
Part: #BC812MSM
UPC: 782856198109
Next day delivery
Description
BC-MSM Conduit to Beam Clamp – Electrical Distributor Solutions
The BC-MSM Conduit to Beam Clamp, Side Mount, is engineered for secure and efficient attachment of conduit to beam flanges. It supports 1/2" and 3/4" EMT, as well as 1/2" and 3/4" rigid pipe with outer diameters ranging from 0.709" to 1.181". Designed for electrical distributors and lighting solutions, this clamp eliminates the need for offset bending of conduit, streamlining installation in wire and cable applications. As a reliable component from a trusted switchgear supplier, it ensures stable conduit mounting with a maximum flange thickness of 0.5".
- Material: Spring Steel
- Finish: nVent CADDY Armour
- Outer Diameter Range: 18 – 30 mm (0.709" – 1.181")
- Flange Thickness: Maximum 12.7 mm (0.5")
- Torque: 3 N·m
- Static Load Capacity: 120 N
- Compatible Conduit Sizes: 1/2" and 3/4" EMT, 1/2" and 3/4" Rigid/Pipe
- Manufacturer Part Number: BC812MSM
- Made in USA
Specifications
- Easy installation to beam flanges reduces labor time
- Eliminates offset bending of conduit for cleaner installations
- 360-degree rotating conduit clip for flexible positioning
- Durable spring steel construction with protective Armour finish
- UL certified for quality and safety compliance
