Features

• Our Beam Attachments and Pipe Supports Offered in this Section are Designed to Provide Supports without Drilling or Welding
• A Complete Selection of Beam Clamps, Pipe Clamps, Rollers, Supports and Accessories are Designed for Use with B-Line Channels and Offer Many Installation Advantages
• It is the Process by Which a Coating of Zinc is Deposited on the Steel by Electrolysis from a Bath of Zinc Salts
• When Exposed to Air and Moisture, Zinc Forms a Tough, Adherent, Protective Film Consisting of a Mixture of Zinc Oxides, Hydroxides and Carbonates
• This Film is in Itself a Barrier Coating Which Slows Subsequent Corrosive Attack on the Zinc
• This Coating is Usually Recommended for Indoor Use in Relatively Dry Areas, as it Provides Ninety-Six Hours Protection in Salt Spray

Additional Information

• Overall Dimension 3 Inch Length x 1.875 Inch Width x 1.875 Inch Height
• Thread Size 3/8 Inch-16 TPI
• Includes Set Screw

Specifications

• Maximum Jaw Capacity: 3/4 Inch
• Supplied with Screw: Yes
• Screw Size: 1/2 Inch-13 TPI
• Load Capacity: 350 Pound
• Material: Malleable Iron
• Material Specification: ASTM B633 SC3 Type III/ASTM A653
• Finish: Zinc Electroplated
• Application: Channel
• Series/Model: B444
