Aluminum Universal Terminal, 1 Hole, 500-1000 kcmil, 1/2" Stud, 1 Screw, Al/Cu Rated, Tin Plated
SKU: #331461
Part: #KA44U
UPC: 781810370353
Aluminum Universal Terminal, 1 Hole, 500-1000 kcmil, 1/2" Stud, 1 Screw, Al/Cu Rated, Tin Plated
SKU: #331461
Part: #KA44U
UPC: 781810370353
Description
Aluminum Universal Terminal, 1 Hole, 500-1000 kcmil, 1/2" Stud, Al/Cu Rated – Electrical Terminal
This Aluminum Universal Terminal is designed for use with aluminum and copper conductors, providing a reliable connection solution for electrical distributors and switchgear suppliers. It is suitable for wire sizes ranging from 500 to 1000 kcmil and features a single hole and stud configuration optimized for panelboard applications. The terminal is tin-plated to ensure low contact resistance and durability in electrical installations.
Specifications
- Material: Aluminum
- Plating Type: Tin
- Application: For Aluminum And Copper Conductors
- Number of Conductors: 1
- Connection Type: Terminal
- Hole Size: 0.53 inches
- Stud Size: 1/2 inch
- Width: 1.77 in
- Height: 1.95 in
- Length Overall: 3.50 in
- Installation Torque Recommended: 550 in-lb
- Country of Origin: United States
- Made in USA: Yes
- Manufacturer: Burndy
- Manufacturer Part Number: KA44U
- Industry Standard: UL 486A-486B
- UL Listed: Yes
- CSA Approved: Yes
- RoHS Compliance Status: EX
Features
- Dual rated for aluminum and copper conductors
- Constructed from high strength extruded aluminum alloy
- Electro tin-plated for low contact resistance
- Single screw and hole design for secure connection
- Allen screw type for reliable fastening
